(.075mil spacing) Spring Probe (.250 Stroke) - TX-TOP075 (Pack of 25 @ $5.40/ea)

Hover over image to zoom

  • Image 1
  • Image 2
  • Image 3
  • Image 4
  • Image 5
$135.00
Weight:
0.20 LBS
Shipping:
Calculated at checkout

 Product Description

Probe Specifications

Minimum Centers: 1.91mm[0.075inch]
Full Stroke: 6.35mm[0.250inch]
Recommand Stroke: 4.25mm[0.167inch]
Spring Force: 200g[7.054oz]
Impedance: 20milliohms
Current: 3AMP
Temperature: -55? to 120 ?[-67°F to 248°F]
Spring Life: 1000K cycles
Diameter Tolerance: ±0.01mm[±0.39mil]
Length Tolerance: ±0.10mm[±3.93mil]
Straightness Tolerance: 0.05mm[1.97mil]

Materials Specifications

Plunger: SK-4, BeCu, Au plating treatment
Spring: Music wire, Au plating treatment
Barrel: Phosphor Copper, Au plating treatment
